HFM Series Centrifugal Type Water Pump
Application
These pumps can handle fluids that are not chemically aggressive to the pump's components, such as pure water devoid of abrasive particles.
They find many uses in home and civil applications, and in particular the automatic distribution of water from small and medium-sized surge tanks, transporting water, watering gardens, etc. They are incredibly dependable, easy to use, quiet, and practically maintenance free.
Working conditions
Max temperature of Fluid up to +60℃
Max Ambient Temperature up to 40℃
Suction lift up to 8m
Technical data
Technical Description
1. motor
100% copper winding coil, machine wiring,new material stator,low temperature rise,stable working
(aluminum winding coil for your choice available,different stator length for your choice also）
2. Impeller
Brass material
Stainless steel material
Aluminum material
Plastic material
3. Rotor and shaft
Surface moisture proof ,anti rust treatment
Carbon steel shaft or 304 stainless steel shaft
Exploded View
Production line
Quality control
heed the ISO 9001 quality management system.
From conception to testing to approval prior to acceptance, from a sample to a batch purchase
The materials from our vendors are inspected before entering our warehouse.
to create a quality control plan and operation instructions.
It was discovered by test equipment during production, and a second spot check was performed before to distribution.
Installation instruction
It is necessary for the area where the pumps are to be well-ventilated, dry, and with an ambient temperature of no higher than 40°C (Fig.A). To stop vibration, mount the pump securely on a level, firm surface using the proper bolts. The bearings must be in a horizontal position for the pump to function properly. The intake pipe's diameter cannot be less than the intake motor's. Use a pipe with a bigger diameter if the intake height is higher than 4 meters. The deliverypipe's diameter must be selected to match the flow rate and pressure necessary at the takeoff sites. To avoid the development of air locks, the intake pipe must be slightly inclined up toward the intake mouth.
Packing
a wooden box, a honeycomb box, or an interior carton box with a different color
Transportation
Priority bulk cargo or full container loading in the ports of Ningbo, Shanghai, and Yiwu.
Samples
If the sample is expensive, there may be a fee; if you place a formal order, consider a charge refund. Could check sample shipment by land, sea, or even air as you like.
Payment term
T/T term: 20% deposit in advance, 80% balance against copy of bill of lading
L/C term: usually payable at sight
D/P term, 20% deposit in advance, 80% balance of D/P at sight
Credit insurance: 20% down payment first, 80% balance OA 60 days after the insurance company gives us the report
Warranty
The warranty period for the product is 13 months (calculatedfrom the date of bill of lading). If there is a manufacturing quality issue that belongs to the supplier during the warranty period, according to the pertinent vulnerable parts and components, the supplier must be liable for delivering orreplacing the repair parts following the joint identificationand certification of both parties. There is no mention of accessories in the quotation for conventional goods. According to the real feedback, we will negotiate to offer vulnerable components for maintenance throughout the warranty term, and some parts may need to be purchased for a cost. You can submit any quality issues for investigation and negotiation.
